Product Overview
The CGS Tool 142-7500 is basically a 3/4" diameter 4-flute solid carbide ball end mill made for, larger profile and contour work, where a broad .375" radius handles curved pockets and does surface blending across bigger features. It’s of a single-end setup with a 30° helix, so this 142 Series cutter ends up dependable for general purpose ball-end performance, plus the uncoated carbide body fits standard CNC machining over common materials.
Tool Specifications:
- Diameter: 3/4"
- Shank: 3/4"
- Length of Cut (LOC): 1-1/2"
- Overall Length (OAL): 4"
- Flutes: 4 - Ball End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: .375"
- Series: CGS 142 Series
- Part No: 142-7500
Key Performance Features:
- Larger contour milling handled by a 4-flute ball end design
- .375" radius supports broad rounded surface work
- 30° helix gives controlled, general-purpose cutting
- Suited to finishing, blending, and curved pocket machining
- Single-end solid carbide construction
- Performs across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites
