Product Overview
The CGS Tool 2002 has a 5/32” diameter, 2-flute solid carbide square end mill, made for max material removal plus a clean surface finish on the materials like aluminum, other non-ferrous metals, and plastics. The tool is a part of the Ferocious Series, so it’s aimed at machinists who want big time performance, even when you’re running those extreme feed rates.
Built with premium sub-micro grain carbide, the 2002 comes with a 55° high helix, mainly for chip clearing that stays smooth, less cutting force, and pretty outstanding surface quality. You get polished cutting edges and a free-cutting style too, which helps lower built-up edges, while still keeping excellent tool life, even when the job is high-speed CNC work.
Tool Specifications:
- Diameter: 5/32”
- Shank: 5/32”
- Length of Cut (LOC): 3/4”
- Overall Length (OAL): 2”
- Flutes: 2 - Square End
- Material: Solid Micro-Grain Carbide
- Coating: Bright (Uncoated)
- Series: CGS Ferocious
- Part No: 2002
Key Performance Features:
- 2-Flute, 55° High Helix design for aluminum and non-ferrous machining
- Ultra-smooth polished land for superior surface finish
- Capable of extreme RPM and feed rates
- Excellent chip evacuation and edge strength
- Ideal for roughing, slotting, and contouring applications
- Reduced neck & Weldon flats available upon request
- ZrN coating option available for extended life and cleaner cuts
