Product Overview
Tough milling at 7/16" diameter is where the CGS Tool 3015 goes to work — a 3-flute square end mill from the Storm 3000 Series built for chip load capacity and cutting strength in steels, stainless, cast iron, titanium, alloys, Inconel, and select non-ferrous materials.
A 60° high helix shears fast, and a heavy core with eccentric relief geometry gives the tool the backbone to handle demanding production work. Uncoated solid carbide construction means this one's built to Storm into applications where an ordinary tool wouldn't hold up.
Tool Specifications:
- Diameter: 7/16"
- Shank: 7/16"
- Length of Cut (LOC): 1"
- Overall Length (OAL): 3"
- Flutes: 3 - Square End
- Material: Solid Carbide
- Coating: Uncoated
- Helix: 60°
- Design: Single End
- Series: CGS Storm 3000 Series
- Part No: 3015
Key Performance Features:
- 3-flute square end design built for tough milling applications
- 60° high helix supports fast shearing action and smooth cutting
- Heavy core construction helps the tool handle high chip loads
- Eccentric relief design adds toughness during demanding cuts
- Solid carbide body provides rigidity and wear resistance
- Built for steels, stainless, cast iron, titanium, alloys, Inconel, and select non-ferrous materials
- Strong choice for rugged production milling and heavy stock removal
