Product Overview
The CGS Tool 422-0469 is a 3/64" diameter 2-flute solid carbide ball end mill from the 422 Series, built with a double-end design for tiny contour details and fine profile work where a very small radius cutter is needed. It's built for careful, delicate milling.
Built on the same precision CNC equipment as CGS Tool's other general-purpose lines, it holds a 30° helix and a .0234" radius matched precisely to its diameter for good control. Uncoated and rated across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites, it's practical for small rounded features.
Tool Specifications:
- Diameter: 3/64"
- Shank: 1/8"
- Length of Cut (LOC): 3/32"
- Overall Length (OAL): 1-1/2"
- Flutes: 2 - Ball End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: .0234"
- Series: CGS General Purpose (422 Series)
- Part No: 422-0469
Key Performance Features:
- 2-Flute ball end design for fine contour milling
- Double-end body extends usable cutting value
- .0234" radius matched to diameter for tiny rounded details
- 30° helix with precision-ground cutting edges
- Effective across mild steels, stainless, cast iron, and titanium
- Also suited to non-ferrous metals, plastics, and composites
