Product Overview
The CGS Tool 720-1000 is a 1" diameter 2-flute solid carbide square end mill from the 720 Series, sized for shops that need a larger cutter without complicating the setup. It sits in that useful spot between a standard mid-size end mill and a true heavy-duty roughing tool.
Built on the same precision CNC equipment as CGS Tool's other general-purpose lines, it holds a 30° helix that keeps the cut controlled even as diameter goes up. Uncoated and rated across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites, it's a dependable choice whenever a job calls for stronger material removal.
Tool Specifications:
- Diameter: 1"
- Shank: 1"
- Length of Cut (LOC): 2-1/4"
- Overall Length (OAL): 5"
- Flutes: 2 - Square End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: No
- Series: CGS General Purpose (720 Series)
- Part No: 720-1000
Key Performance Features:
- 2-Flute square end design for roughing and finishing
- Larger 1" diameter matched to stronger material removal
- 30° helix with precision-ground cutting edges
- Uncoated construction for cost-effective general milling
- Effective across mild steels, stainless, cast iron, and titanium
- Also suited to non-ferrous metals, plastics, and composites
