Product Overview
Small-diameter aluminum contouring with real feed capability — the CGS Tool BN5301 is a 1/8" diameter 3-flute ball end mill from the BN5300 Ferocious 3X Series built for smooth finishes at aggressive speeds.
The ball nose handles curved radius work cleanly, and variable helix, variable pitch, and a wiper-style design reduce chatter and harmonics even under fast feeds. Uncoated carbide construction is best suited for aluminum, copper, brass, non-ferrous materials, plastics, and composites.
Tool Specifications:
- Diameter: 1/8"
- Shank: 1/8"
- Length of Cut (LOC): 1/2"
- Overall Length (OAL): 1-1/2"
- Flutes: 3 - Ball End
- Radius: .0625"
- Material: Solid Carbide
- Coating: Uncoated
- Helix: Variable Helix
- Design: Single End
- Series: CGS BN5300 Ferocious 3X Series
- Part No: BN5301
Key Performance Features:
- 3-flute ball end design for high-performance contouring and finishing
- Ferocious 3X geometry supports aggressive non-ferrous machining
- Variable helix and variable pitch help reduce chatter and harmonics
- Wiper-style geometry helps improve surface finish at higher feed rates
- Solid carbide construction provides rigidity and precision
- Best suited for aluminum, copper, brass, non-ferrous materials, plastics, and composites
- Built for 3D profiling, radius milling, surface blending, and finishing passes
