Product Overview
Aluminum shops running aggressive feeds need a tool that won't chatter its way through the cut, and that's where the CGS Tool BN5357 comes in — a 3/4" diameter 3-flute solid carbide ball end mill from the Ferocious 3x BN5300 Series. It's purpose-built for non-ferrous contour milling, the of job where chip movement and surface finish both matter at the same time.
A .375" radius gives it a broad ball-end form for curved profile work, and the geometry doesn't stop there — variable helix, variable pitch, and a wiper end all work together to knock down chatter and harmonics while keeping feeds strong. It's built specifically for aluminum, copper, brass, non-ferrous materials, plastics, and composites.
Tool Specifications:
- Diameter: 3/4"
- Shank: 3/4"
- Length of Cut (LOC): 1-1/2"
- Overall Length (OAL): 4"
- Flutes: 3 - Ball End
- Material: Solid Carbide
- Coating: Uncoated
- Series: CGS BN5300 / Ferocious 3x Series
- Part No: BN5357
Key Performance Features:
- 3-flute ball end built for non-ferrous contour milling
- .375" radius supports broad rounded profile work
- Wiper end geometry improves surface finish
- Variable helix and variable pitch cut down chatter and harmonics
- Built to hold up under strong feeds and heavy stock removal
- Ideal for aluminum, copper, brass, non-ferrous materials, plastics, and composites
