Product Overview
Very fine general-purpose milling needs a genuinely compact tool, and the 120-0312 provides one at 1/32" diameter. This 2-flute square end mill is useful for tiny slots, miniature profiles, delicate plunge cuts, and clean flat-bottom details where careful tool control matters.
Built with a 30° helix and single-end construction, this 120 Series cutter gives controlled cutting action in very small CNC features. Its uncoated carbide body makes it practical for standard shop conditions and light precision work.
Tool Specifications:
- Diameter: 1/32"
- Shank: 1/8"
- Length of Cut (LOC): 3/32"
- Overall Length (OAL): 1-1/2"
- Flutes: 2 Flute
- End Style: Square End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: No
- Series: 120 Series
- Part No: 120-0312
Key Performance Features:
- 2-flute square end built for miniature milling work
- 1/32" diameter supports very small features
- 30° helix helps maintain controlled chip movement
- Compact length of cut supports precise cutting in fine details
- Handles tiny slots, profiles, plunge cuts, and flat-bottom work
- Cuts mild steel, stainless, cast iron, titanium, non-ferrous, plastics, and composites
