Product Overview
Tiny curved details need a tiny tool, and the CGS Tool 442-0312 is built for exactly that — a 1/32" diameter 4-flute ball end mill with cutting edges on both ends, made for miniature contour milling.
A .0156" radius gives a fine ball-end form for very small curved surfaces, and the double-end design means this tool gives two working edges before it's spent. Compact dimensions throughout make it suited to detailed CNC applications across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites.
Tool Specifications:
- Diameter: 1/32"
- Shank: 1/8"
- Length of Cut (LOC): 1/16"
- Overall Length (OAL): 1-1/2"
- Flutes: 4 - Ball End
- Material: Solid Carbide
- Coating: Uncoated
- Series: CGS 442 Series
- Part No: 442-0312
Key Performance Features:
- 4-flute ball end built for miniature contour milling
- Double-end construction gives use from both cutting ends
- .0156" radius supports very small rounded feature work
- Compact LOC supports control in fine details
- Good for finishing, blending, and tiny pocket work
- Suitable for mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites
