Product Overview
The CGS Tool 120-3750 is a 3/8" diameter 2-flute solid carbide square end mill built for general-purpose milling, a dependable pick for slotting, profiling, and side wall work in compact-to-mid-size applications.
With a 1" length of cut and 2-1/2" overall length, this 120 Series tool gives practical reach, and the uncoated carbide body makes it suitable for standard shop conditions.
Tool Specifications:
- Diameter: 3/8"
- Shank: 3/8"
- Length of Cut (LOC): 1"
- Overall Length (OAL): 2-1/2"
- Flutes: 2 - Square End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: No
- Series: CGS 120 Series
- Part No: 120-3750
Key Performance Features:
- General-purpose milling handled by a 2-flute square end design
- 3/8" diameter supports controlled stock removal
- 30° helix supports smooth chip movement
- Suited to slotting, profiling, plunge, and side wall milling
- Single-end solid carbide construction
- Performs across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites
