Product Overview
The CGS Tool 120-8750 is a 7/8" diameter 2-flute solid carbide square end mill from the 120 Series, sized for larger general-purpose milling that calls for a wide cutter without moving into a specialized high-performance line. It handles roughing, finishing, slotting, and side wall milling in one straightforward tool.
Built on the same precision CNC equipment as CGS Tool's other general-purpose lines, it holds a 30° helix matched to its larger diameter for smooth, predictable cutting. Uncoated and rated across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites, it's a dependable choice for heavier stock removal.
Tool Specifications:
- Diameter: 7/8"
- Shank: 7/8"
- Length of Cut (LOC): 1-1/2"
- Overall Length (OAL): 4"
- Flutes: 2 - Square End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: No
- Series: CGS General Purpose (120 Series)
- Part No: 120-8750
Key Performance Features:
- 2-Flute square end design for general-purpose milling
- Larger diameter matched to heavier stock removal
- 30° helix with precision-ground cutting edges
- Uncoated construction for standard machining setups
- Effective across mild steels, stainless, cast iron, and titanium
- Also suited to non-ferrous metals, plastics, and composites
