Product Overview
The CGS Tool 140-1000 is a 1" diameter 4-flute solid carbide square end mill built for larger general-purpose roughing and finishing, where a full-inch diameter gives the strength to handle heavy slots and side walls.
With a 1-1/2" length of cut and 4" overall length, this 140 Series cutter gives strong performance in larger CNC features, and the 30° helix combined with uncoated carbide body works well across many common shop materials.
Tool Specifications:
- Diameter: 1"
- Shank: 1"
- Length of Cut (LOC): 1-1/2"
- Overall Length (OAL): 4"
- Flutes: 4 - Square End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: No
- Series: CGS 140 Series
- Part No: 140-1000
Key Performance Features:
- Larger milling work handled by a 4-flute square end design
- 1" diameter supports stronger stock removal
- 30° helix supports smooth chip movement
- Suited to slotting, profiling, plunge, and side wall milling
- Single-end solid carbide construction
- Performs across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites
