Product Overview
The CGS Tool 140-3594-ALTiN is a 23/64" diameter 4-flute solid carbide square end mill built for general-purpose roughing and finishing, useful for slots, profiles, plunge cuts, and clean flat-bottom applications.
The ALTiN coating adds heat and wear resistance under tougher cutting conditions, and with a 7/8" length of cut, 2-1/2" overall length, and 30° helix, this 140 Series cutter gives dependable square-end performance across many CNC materials.
Tool Specifications:
- Diameter: 23/64"
- Shank: 3/8"
- Length of Cut (LOC): 7/8"
- Overall Length (OAL): 2-1/2"
- Flutes: 4 - Square End
- Material: Solid Carbide
- Coating: ALTiN
- Radius: No
- Series: CGS 140 Series
- Part No: 140-3594-ALTiN
Key Performance Features:
- Roughing and finishing covered by a 4-flute square end design
- 23/64" diameter supports controlled stock removal
- ALTiN coating adds heat and wear resistance
- 30° helix keeps chip movement smooth
- Suited to slotting, profiling, plunge, and side wall milling
- Performs across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites
