Product Overview
The CGS Tool 142-6875 is an 11/16" diameter 4-flute solid carbide ball end mill built specifically for larger profile and contour work, where the surface needs a broad, smooth transition rather than a tight, detailed one. It belongs to the 142 Series, CGS Tool's general-purpose ball nose line scaled up for bigger features.
What sets this tool apart is the .3437" radius, which gives a wide rounded cutting form well suited to curved pockets and surface blending at scale. With a 1-1/2" length of cut and 30° helix, it delivers dependable reach and control, and left uncoated, it holds up through mild steel, stainless, cast iron, titanium, non-ferrous material, plastics, and composites.
Tool Specifications:
- Diameter: 11/16"
- Shank: 3/4"
- Length of Cut (LOC): 1-1/2"
- Overall Length (OAL): 4"
- Flutes: 4 - Ball End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: .3437"
- Series: CGS 142 Series
- Part No: 142-6875
Key Performance Features:
- 4-flute ball end design built for larger contour milling
- .3437" radius supports broad, rounded surface work
- 30° helix gives steady general-purpose cutting
- Handles finishing, blending, and curved pocket machining
- Single-end solid carbide build
- Rated for mild steel, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites
