Product Overview
Larger contour work needs a broad radius plus coating protection, and the 142-6875-ALTiN sort of does both, at 11/16" diameter with a .3437" radius. This 4-flute ball end mill gives machinists a broad rounded cutting shape for surface blending, curved pocket work, and finishing use cases.
ALTiN coating helps boost heat and wear resistance when milling gets tougher. With a 1-1/2" length of cut, 4" overall length, and a 30° helix angle, this 142 Series cutter delivers dependable ball end action across many materials.
Tool Specifications:
- Diameter: 11/16"
- Shank: 3/4"
- Length of Cut (LOC): 1-1/2"
- Overall Length (OAL): 4"
- Flutes: 4 Flute
- End Style: Ball End
- Material: Solid Carbide
- Coating: ALTiN
- Radius: .3437"
- Series: 142 Series
- Part No: 142-6875-ALTiN
Key Performance Features:
- 4-flute ball end built for larger contour milling
- .3437" radius supports broad, rounded surface work
- ALTiN coating improves heat and wear resistance
- 30° helix supports steady, general-purpose cutting
- Handles finishing, blending, and curved pocket machining
- Cuts mild steel, stainless, cast iron, titanium, non-ferrous, plastics, and composites
