Product Overview
Compact general-purpose work is a handled by the CGS Tool 220-1875, sort of a 3/16" diameter 2-flute square end mill from the 220 Series. It’s built for smaller slots, profiles, plunge cuts and side wall work too, without much fuss.
A 3/8" length of cut and 2" overall length keep this tool proportioned for smaller CNC features, and a 30° helix keeps chip movement smooth throughout. Uncoated carbide construction handles everyday milling across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites.
Tool Specifications:
- Diameter: 3/16"
- Shank: 3/16"
- Length of Cut (LOC): 3/8"
- Overall Length (OAL): 2"
- Flutes: 2 - Square End
- Material: Solid Carbide
- Coating: Uncoated
- Series: CGS 220 Series
- Part No: 220-1875
Key Performance Features:
- 2-flute square end built for compact milling work
- 3/16" diameter supports small machining features
- 30° helix keeps chip movement smooth
- Good for slotting, profiling, plunge, and side wall milling
- Single-end solid carbide construction
- Suitable for mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites
