Product Overview
The CGS Tool 220-6250 is a 5/8" diameter 2-flute solid carbide square end mill built for general-purpose milling where the job calls for more stock removal than a smaller diameter tool can provide. Slotting, profiling, plunge cutting, and clean flat-bottom work all sit comfortably in its range.
With a 3/4" length of cut and 3" overall length, this 220 Series tool provides controlled stock removal in mid-size milling work, and the 30° helix combined with uncoated carbide construction gives it solid performance across many common CNC materials.
Tool Specifications:
- Diameter: 5/8"
- Shank: 5/8"
- Length of Cut (LOC): 3/4"
- Overall Length (OAL): 3"
- Flutes: 2 - Square End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: No
- Series: CGS 220 Series
- Part No: 220-6250
Key Performance Features:
- Mid-size stock removal handled by a 2-flute square end design
- 5/8" diameter supports stronger material removal
- 30° helix keeps chip movement steady
- Handles slotting, profiling, plunge, and side wall milling
- Single-end solid carbide construction
- Suited to mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites
