Product Overview
Extended-reach contouring is the specialty of the CGS Tool 8006-ALTiN, a 5/16" diameter 4-flute ball end mill from the long-reach 8000 Profile Series built for deep pocket and 3D milling work.
A 4" overall length adds real access, and ALTiN coating protects the edge through the heat that builds up over extended cutting. Solid carbide construction handles mild steels, stainless, cast iron, titanium, non-ferrous materials, plastics, and composites.
Tool Specifications:
- Diameter: 5/16"
- Shank: 3/8"
- Length of Cut (LOC): 1/2"
- Overall Length (OAL): 4"
- Flutes: 4 - Ball End
- Material: Solid Carbide
- Coating: ALTiN
- Radius: .1562"
- Helix: 30°
- Design: Single End
- Series: CGS 8000 Profile Series
- Part No: 8006-ALTiN
Key Performance Features:
- 4-flute ball end design for contouring and profile milling
- Extended overall length supports deep pocket applications
- ALTiN coating helps improve heat resistance and cutting edge life
- 30° helix supports smooth cutting and controlled chip flow
- Solid carbide construction provides rigidity for extended-reach work
- Suitable for mild steels, stainless, cast iron, titanium, non-ferrous materials, plastics, and composites
- Built for deep pocket milling, 3D profiling, finishing, and surface blending
