Product Overview
When spindle load starts becoming the bottleneck, shops reach for the CGS Tool 1001-ALTiN — a 1/8" diameter 4-flute square end mill from the Beast 1000 Series, built for roughing and slot milling where cutting strength matters more than finesse.
CGS Tool's chip breaker geometry cuts down cutting pressure and supports faster feeds, and ALTiN coating adds heat and wear resistance for tougher roughing conditions. A variable helix smooths out the roughing pass, and this tool is rated for steels, stainless, cast iron, titanium, alloys, Inconel, and select non-ferrous materials.
Tool Specifications:
- Diameter: 1/8"
- Shank: 1/8"
- Length of Cut (LOC): 1/2"
- Overall Length (OAL): 1-1/2"
- Flutes: 4 - Square End
- Material: Solid Carbide
- Coating: ALTiN
- Series: CGS Beast 1000 Series
- Part No: 1001-ALTiN
Key Performance Features:
- 4-flute square end built for roughing and slot milling
- Beast chip breaker design reduces spindle load
- ALTiN coating adds heat and wear resistance
- Variable helix supports smoother roughing performance
- Good for aggressive milling and slotting applications
- Ideal for steels, stainless, cast iron, titanium, alloys, Inconel, and select non-ferrous materials
