Product Overview
The CGS Tool 1001 is a 1/8" diameter 4-flute solid carbide square end mill from the Beast Series, sized for roughing and slot milling where a smaller cutter still needs to remove material quickly. It's built for shops that need more efficiency out of a compact roughing tool.
CGS Tool's chip breaker design is matched to support faster feeds and reduce spindle load, exactly what machinists want from a compact roughing end mill. Rated for steels, stainless steel, cast iron, titanium, alloys, Inconel, and select non-ferrous materials, it holds up under stronger feed conditions.
Tool Specifications:
- Diameter: 1/8"
- Shank: 1/8"
- Length of Cut (LOC): 1/2"
- Overall Length (OAL): 1-1/2"
- Flutes: 4 - Square End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: No
- Series: Beast Series
- Part No: 1001
Key Performance Features:
- 4-Flute square end design for roughing and slot milling
- Chip breaker geometry matched to reduced spindle load
- Built for faster feeds in demanding applications
- Solid carbide construction gives strength and stability
- Effective across steels, stainless, cast iron, and titanium
- Also suited to alloys, Inconel, and select non-ferrous materials
