Product Overview
The CGS Tool 840-6250 is a 5/8" diameter 4-flute solid carbide square end mill built specifically for long-reach general-purpose milling, sitting between a standard tool and a full extra-long-reach cutter. It belongs to the 840 Series, CGS Tool's long-reach general-purpose line.
What sets this tool apart is a 3" length of cut on a 5/8" diameter, giving useful extra depth for side walls and slotting without going to an extreme-reach tool. Running a 30° helix, and left uncoated, it holds up through mild steel, stainless, cast iron, titanium, non-ferrous material, plastics, and composites.
Tool Specifications:
- Diameter: 5/8"
- Shank: 5/8"
- Length of Cut (LOC): 3"
- Overall Length (OAL): 6"
- Flutes: 4 - Square End
- Material: Solid Carbide
- Coating: Uncoated
- Series: CGS 840 Series
- Part No: 840-6250
Key Performance Features:
- 4-flute square end design for long-reach milling
- 3" LOC gives extended cutting depth
- 6" OAL supports deeper machining access
- 30° helix supports smooth general-purpose cutting
- Handles slotting, profiling, plunging, and side wall milling
- Rated for mild steel, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites
