Product Overview
The CGS Tool BN2006 has a 1/4” diameter 2-flute solid carbide ball end mill. It is meant for high-speed machining on aluminum, non-ferrous metals, plastics, and composite parts. And as part of the BN2000 Series Ferocious, it’s supposed to bring great material removal rates, nicer surface finishes, and dependable overall behavior when you push it in CNC milling tasks that are honestly pretty demanding.
It’s made from premium solid carbide, and the BN2006 has CGS Tool’s own 55° high helix geometry, which helps with chip evacuation, plus it helps lower cutting forces. The precision-ground ball end shape makes it a good fit for contouring, profiling, and 3D surface machining, while the uncoated cutting edges keep the cutting action clean. In aluminum, and other non-ferrous materials, this kind of setup also helps minimize material buildup that can become annoying over time.
Tool Specifications:
- Diameter: 1/4”
- Shank: 1/4”
- Length of Cut (LOC): 3/4”
- Overall Length (OAL): 2-1/2”
- Flutes: 2 - Ball End
- Radius: .125”
- Material: Solid Carbide
- Coating: Uncoated
- Series: BN2000 Series Ferocious
- Part No: BN2006
Key Performance Features:
- 2-Flute ball end design for contouring and profiling applications
- Original 55° high helix geometry for superior chip evacuation
- Uncoated cutting edges optimized for aluminum and non-ferrous materials
- Supports high chip loads and aggressive feed rates
- Produces smooth surface finishes in complex machining operations
- Ideal for 3D machining, finishing, and sculptured surfaces
- Excellent performance in aluminum, copper, brass, plastics, and composites
- Engineered for high-speed CNC milling and efficient material removal
