Product Overview
The CGS Tool CR123-1000.060 i s basically built around added corner strength for bigger jobs, you know, the stuff that hits harder. It’s a 1" diameter 2-flute corner radius end mill from the CR123 Series, with a .060" radius that helps keep those machined corners feeling consistent even when the cutting loads get heavier.
Then there’s the 30° helix and the uncoated carbide construction, which really rounds it out. Overall this cutter is handy for slotting, profiling, shoulder work, and side wall milling. It's built for mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites.
Tool Specifications:
- Diameter: 1"
- Shank: 1"
- Length of Cut (LOC): 1-1/2"
- Overall Length (OAL): 4"
- Flutes: 2 - Corner Radius
- Material: Solid Carbide
- Coating: Uncoated
- Series: CGS CR123 Series
- Part No: CR123-1000.060
Key Performance Features:
- 2-flute corner radius design for larger milling work
- .060" radius improves cutting-edge strength
- 30° helix supports smooth cutting control
- Good for slotting, profiling, shoulder work, and side wall milling
- Single-end solid carbide construction
- Works in mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites
