Product Overview
The CGS Tool CR123-3750.015 is basically a 3/8" diameter 2-flute solid carbide corner radius end mill, it is made for general purpose milling where that .015" corner radius helps the cutting edge stay supported and it keeps the machined corners a clean.
It uses single-end construction and a 30° helix too, so this CR123 Series cutter works well for slotting, profiling, shoulder work, and side wall milling. Also the uncoated carbide body, tends to hold up across typical shop conditions and the more common CNC materials you run every day.
Tool Specifications:
- Diameter: 3/8"
- Shank: 3/8"
- Length of Cut (LOC): 1"
- Overall Length (OAL): 2-1/2"
- Flutes: 2 - Corner Radius
- Material: Solid Carbide
- Coating: Uncoated
- Radius: .015"
- Series: CGS CR123 Series
- Part No: CR123-3750.015
Key Performance Features:
- General-purpose milling handled by a 2-flute corner radius design
- .015" radius reduces sharp-corner wear
- 30° helix gives smooth cutting control
- Suited to slotting, profiling, shoulder work, and side wall milling
- Single-end solid carbide construction
- Performs across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites
