Product Overview
Larger-format corner radius work is the specialty of the CGS Tool CR123-7500.020, a 3/4" diameter 2-flute cutter from the CR123 Series. The .020" corner radius keeps machined corners consistent across bigger square-profile jobs where edge strength really matters.
A 30° helix keeps cutting under control, and the uncoated carbide body handles the demands of slotting, profiling, shoulder work, and side wall milling without needing extra coating. This one's built for mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites.
Tool Specifications:
- Diameter: 3/4"
- Shank: 3/4"
- Length of Cut (LOC): 1-1/2"
- Overall Length (OAL): 4"
- Flutes: 2 - Corner Radius
- Material: Solid Carbide
- Coating: Uncoated
- Series: CGS CR123 Series
- Part No: CR123-7500.020
Key Performance Features:
- 2-flute corner radius design for larger general-purpose milling
- .020" radius improves cutting-edge strength
- 30° helix gives smooth cutting control
- Good for slotting, profiling, shoulder work, and side wall milling
- Single-end solid carbide construction
- Works in mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites
