Product Overview
Bigger diameter bigger corner protection vibe, uh, the CGS Tool CR143-7500.060-ALTiN is basically this 3/4" diameter, 4-flute corner radius end mill, from the CR143 Series and it’s designed to hold up when there’s heavier cutting engagement.
A .060" radius keeps sharp-edge wear in check, and ALTiN coating helps the tool withstand heat over extended edge life. Solid carbide construction handles mild steels, stainless, cast iron, titanium, non-ferrous materials, plastics, and composites.
Tool Specifications:
- Diameter: 3/4"
- Shank: 3/4"
- Length of Cut (LOC): 1-1/2"
- Overall Length (OAL): 4"
- Flutes: 4 - Corner Radius
- Corner Radius: .060"
- Material: Solid Carbide
- Coating: ALTiN
- Helix: 30°
- Design: Single End
- Series: CGS CR143 Series
- Part No: CR143-7500.060-ALTiN
Key Performance Features:
- 4-flute corner radius design strengthens the cutting edge
- .060" radius helps reduce corner chipping and premature wear
- ALTiN coating supports heat resistance in demanding milling conditions
- 30° helix promotes smooth cutting and controlled chip movement
- Solid carbide body provides rigidity and dependable tool life
- Suitable for mild steels, stainless, cast iron, titanium, non-ferrous materials, plastics, and composites
- Built for slotting, profiling, pocketing, and general-purpose milling
