Product Overview
The CGS Tool 120-3125 is basically a 5/16" diameter, 2-flute solid carbide square end mill, made for general purpose milling, which works for slotting and profiling, plus those clean flat bottom jobs in compact-to-mid-size CNC setups. It’s of the go-of tool when you need a reliable, simple cutter.
On top of that, you get a 13/16" length of cut and an overall 2-1/2" length, so you still have a reasonable reach. The uncoated carbide build keeps it appropriate for typical shop conditions, nothing fancy, but it gets the job done.
Tool Specifications:
- Diameter: 5/16"
- Shank: 5/16"
- Length of Cut (LOC): 13/16"
- Overall Length (OAL): 2-1/2"
- Flutes: 2 - Square End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: No
- Series: CGS 120 Series
- Part No: 120-3125
Key Performance Features:
- General-purpose milling handled by a 2-flute square end design
- 5/16" diameter supports controlled stock removal
- 30° helix keeps chip movement smooth
- Suited to slotting, profiling, plunge, and side wall milling
- Single-end solid carbide construction
- Performs across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites
