Product Overview
The CGS Tool 120-3594 is a 23/64" diameter 2-flute solid carbide square end mill built specifically for dependable general-purpose milling where chip clearance matters as much as the cut itself. It belongs to the 120 Series, CGS Tool's standard all-purpose line.
What sets this tool apart is nothing more than consistency — a 30° helix, single-end build, and uncoated carbide body that gives predictable stock removal across slotting, profiling, plunge cutting, side wall work, and flat-bottom features in mild steel, stainless, cast iron, titanium, non-ferrous material, plastics, and composites.
Tool Specifications:
- Diameter: 23/64"
- Shank: 3/8"
- Length of Cut (LOC): 7/8"
- Overall Length (OAL): 2-1/2"
- Flutes: 2 - Square End
- Material: Solid Carbide
- Coating: Uncoated
- Series: CGS 120 Series
- Part No: 120-3594
Key Performance Features:
- 2-flute square end design for general-purpose milling
- 23/64" diameter suits controlled mid-size cutting
- 30° helix supports smooth stock removal
- Handles slotting, profiling, plunging, and side wall milling
- Single-end solid carbide build
- Rated for mild steel, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites
