Product Overview
The CGS Tool 122-3594 is a 23/64" diameter 2-flute solid carbide ball end mill built for profile and contour work, with a .1797" radius that gives a smooth rounded cutting form suited to curved pockets and surface blending.
With a 7/8" length of cut and 2-1/2" overall length, this 122 Series cutter gives practical reach for compact-to-mid-size ball-end work, and the 30° helix combined with uncoated carbide construction performs well across many common CNC materials.
Tool Specifications:
- Diameter: 23/64"
- Shank: 3/8"
- Length of Cut (LOC): 7/8"
- Overall Length (OAL): 2-1/2"
- Flutes: 2 - Ball End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: .1797"
- Series: CGS 122 Series
- Part No: 122-3594
Key Performance Features:
- Profile and contour milling handled by a 2-flute ball end design
- .1797" radius supports smooth rounded surface work
- 30° helix gives steady, general-purpose cutting
- Suited to finishing, blending, and curved pocket machining
- Single-end solid carbide construction
- Performs across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites
