Product Overview
Mid-size general-purpose milling with real removal capability, that's the 120-5625 at 9/16" diameter. This 2-flute square end mill gives machinists a strong cutter for slotting, profiling, plunge cutting, side wall work, and clean flat-bottom applications.
With a 1-1/4" length of cut and 3-1/2" overall length, this 120 Series cutter offers practical reach for mid-size milling work. Built with a 30° helix and uncoated carbide body, it delivers dependable stock removal across many CNC materials.
Tool Specifications:
- Diameter: 9/16"
- Shank: 9/16"
- Length of Cut (LOC): 1-1/4"
- Overall Length (OAL): 3-1/2"
- Flutes: 2 Flute
- End Style: Square End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: No
- Series: 120 Series
- Part No: 120-5625
Key Performance Features:
- 2-flute square end built for general-purpose milling
- 9/16" diameter supports strong stock removal
- 30° helix helps maintain smooth chip movement
- Handles slotting, profiling, plunging, and side wall milling
- Single-end solid carbide construction
- Cuts mild steel, stainless, cast iron, titanium, non-ferrous, plastics, and composites
