Product Overview
The CGS Tool 140-5625 is basically a 9/16" diameter, 4-flute solid carbide square end mill, made for general purpose roughing and then finishing of stuff, it works well for slots, profiles, plunge cuts ,and even clean flat-bottom operations.
You get a 1-1/4" length of cut with a 3-1/2" overall length, so this 140 Series cutter tends to deliver dependable square-end results in mid to large CNC features, and the uncoated carbide body, honestly keeps it practical for the usual shop conditions.
Tool Specifications:
- Diameter: 9/16"
- Shank: 9/16"
- Length of Cut (LOC): 1-1/4"
- Overall Length (OAL): 3-1/2"
- Flutes: 4 - Square End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: No
- Series: CGS 140 Series
- Part No: 140-5625
Key Performance Features:
- Roughing and finishing covered by a 4-flute square end design
- 9/16" diameter supports controlled stock removal
- 30° helix supports smooth chip movement
- Suited to slotting, profiling, plunge, and side wall milling
- Single-end solid carbide construction
- Performs across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites
