Product Overview
small-diameter work, you really want a tool that stays controlled , and the CGS Tool 140-1094 does that at 7/64". It's a 4 flute square end mill from the 140 Series made for very detailed slotting and profiling, where tool size matters more than just raw material removal.
You get that compact 4 flute design with a 30° helix , plus an uncoated finish, so it brings flexibility in general machining, and since it uses a 1/8" shank, this shorter cutter keeps rigidity where a longer tool would probably flex. It goes through mild steels, stainless steel, cast iron , titanium, nonferrous materials, plastics, and composites.
Tool Specifications:
- Diameter: 7/64"
- Shank: 1/8"
- Length of Cut (LOC): 3/8"
- Overall Length (OAL): 1-1/2"
- Flutes: 4 - Square End
- Material: Solid Carbide
- Coating: Uncoated
- Helix: 30°
- Series: CGS 140 Series
- Part No: 140-1094
Key Performance Features:
- 4-flute square end design for precise small-diameter milling
- 30° helix supports smooth cutting and controlled chip movement
- Solid carbide construction provides rigidity and wear resistance
- Uncoated finish suited for flexible general-purpose machining
- Built for mild steels, stainless, cast iron, titanium, non-ferrous materials, plastics, and composites
- Compact tool length helps improve control in detailed milling operations
- Ideal for slotting, profiling, and light stock removal work
