Product Overview
The CGS Tool 140-2031 is a 13/64" diameter 4-flute solid carbide square end mill built specifically for compact general-purpose milling where a clean, controlled cut matters more than reach. It belongs to the 140 Series, CGS Tool's standard general-purpose line.
What sets this tool apart is nothing complicated — a dependable 30° helix, single-end build, and uncoated carbide body that holds up through everyday CNC work: small slots, profiles, plunge cuts, shallow pockets, and flat-bottom features in mild steel, stainless, cast iron, titanium, non-ferrous material, plastics, and composites.
Tool Specifications:
- Diameter: 13/64"
- Shank: 1/4"
- Length of Cut (LOC): 5/8"
- Overall Length (OAL): 2-1/2"
- Flutes: 4 - Square End
- Material: Solid Carbide
- Coating: Uncoated
- Series: CGS 140 Series
- Part No: 140-2031
Key Performance Features:
- 4-flute square end design for compact milling work
- 13/64" diameter suits small-to-mid-size features
- 30° helix supports smooth chip movement
- Handles slotting, profiling, plunging, and side wall milling
- Single-end solid carbide build
- Rated for mild steel, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites
