Product Overview
The CGS Tool 140-2969 is a 19/64" diameter 4-flute solid carbide square end mill from the 140 Series, sized for dependable general-purpose milling where a mid-size cutter needs to remove material steadily. It's a good fit for slotting and profile work without stepping up to a larger tool.
Built on the same precision CNC equipment as CGS Tool's other general-purpose lines, it holds a 30° helix matched to simple, reliable cutting. Uncoated and rated across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites, it works well across a broad mix of shop materials.
Tool Specifications:
- Diameter: 19/64"
- Shank: 5/16"
- Length of Cut (LOC): 13/16"
- Overall Length (OAL): 2-1/2"
- Flutes: 4 - Square End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: No
- Series: CGS General Purpose (140 Series)
- Part No: 140-2969
Key Performance Features:
- 4-Flute square end design for roughing and finishing
- Mid-size diameter matched to versatile milling jobs
- 30° helix with precision-ground cutting edges
- Single-end solid carbide construction
- Effective across mild steels, stainless, cast iron, and titanium
- Also suited to non-ferrous metals, plastics, and composites
