Product Overview
The CGS Tool 2030 is a 1/2” diameter, 2-flute solid carbide square end mill designed for maximum material removal and surface precision in aluminum, non-ferrous metals, and plastics. From the Ferocious Series, this tool is built for machinists who demand high performance at extreme feed rates.
Manufactured from premium sub-micro grain carbide, the 2030 features a 55° high helix for superior chip evacuation, reduced cutting forces, and outstanding surface finishes. Its polished cutting edges and free-cutting geometry minimize built-up edge while maintaining exceptional tool life, even in high-speed CNC applications.
Tool Specifications:
- Diameter: 1/2”
- Shank: 1/2”
- Length of Cut (LOC): 1”
- Overall Length (OAL): 3”
- Flutes: 2 – Square End
- Material: Solid Micro-Grain Carbide
- Coating: Bright (Uncoated) or optional ZrN
- Series: CGS Ferocious
- Part No: 2030
Key Performance Features:
- 2-Flute, 55° High Helix design for aluminum and non-ferrous machining
- Ultra-smooth polished land for superior surface finish
- Capable of extreme RPM and feed rates
- Excellent chip evacuation and edge strength
- Ideal for roughing, slotting, and contouring applications
- Reduced neck & Weldon flats available upon request
- ZrN coating option available for extended life and cleaner cuts
The Ferocious Series is engineered for speed, strength, and precision — helping machinists unleash the full potential of their CNC machines in non-ferrous materials.
