Product Overview
Radius control at 7/16" diameter — the CGS Tool 222-4375 is a 2-flute ball end mill from the single-end 222 Series built for 3D milling, finishing passes, and blended feature work.
The ball nose handles contoured surfaces cleanly, and 2-flute geometry gives helpful chip clearance during milling. Uncoated carbide handles mild steels, stainless, cast iron, titanium, non-ferrous materials, plastics, and composites.
Tool Specifications:
- Diameter: 7/16"
- Shank: 7/16"
- Length of Cut (LOC): 5/8"
- Overall Length (OAL): 2-1/2"
- Flutes: 2 - Ball End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: .2188"
- Helix: 30°
- Design: Single End
- Series: CGS 222 Series
- Part No: 222-4375
Key Performance Features:
- 2-flute ball end design for contouring and radius milling
- Ball nose profile supports smooth 3D surfaces and blended details
- 30° helix supports controlled cutting and chip evacuation
- Solid carbide construction provides rigidity and repeatable accuracy
- Uncoated finish suited for flexible general-purpose machining
- Suitable for mild steels, stainless, cast iron, titanium, non-ferrous materials, plastics, and composites
- Built for profiling, finishing passes, mold work, and surface blending
