Product Overview
The CGS Tool 230-0938 is a 3/32" diameter 3-flute solid carbide square end mill designed for fine general-purpose milling, sized for small slots and light plunge cuts where a compact tool is exactly what the job calls for.
Built with a 45° helix and single-end construction, this 230 Series cutter supports smooth cutting action in small CNC features, and the uncoated carbide body works well across standard shop conditions and mixed CNC materials.
Tool Specifications:
- Diameter: 3/32"
- Shank: 1/8"
- Length of Cut (LOC): 9/64"
- Overall Length (OAL): 1-1/2"
- Flutes: 3 - Square End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: No
- Series: CGS 230 Series
- Part No: 230-0938
Key Performance Features:
- Fine milling work handled by a 3-flute square end design
- 3/32" diameter supports compact machining features
- 45° helix supports smooth cutting action
- Suited to slotting, profiling, plunge, and side wall milling
- Single-end solid carbide construction
- Performs across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites
