Product Overview
Roughing and finishing, across a wide range of materials, thats what the 230-5000 offers at 1/2" diameter. This 3-flute square end mill gives machinists a clean dependable cutter for slotting, profiling, plunge work, and side wall milling where a square end finish is needed.
Made with a steeper 45° helix, and precision cutting edges, this 230 Series tool is meant to keep chip movement steady, plus it helps with consistent material removal. Its uncoated solid carbide body makes it a practical general purpose choice for mild steel, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites, too.
Tool Specifications:
- Diameter: 1/2"
- Shank: 1/2"
- Length of Cut (LOC): 5/8"
- Overall Length (OAL): 2-1/2"
- Flutes: 3 Flute
- End Style: Square End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: No
- Series: 230 Series
- Part No: 230-5000
Key Performance Features:
- 3-flute square end built for rough and finish milling
- 45° helix supports smooth chip movement
- 1/2" diameter gives strong general-purpose cutting capability
- Handles slotting, profiling, plunging, and side wall milling
- Single-end solid carbide construction
- Cuts mild steel, stainless, cast iron, titanium, non-ferrous, plastics, and composites
