Product Overview
The CGS Tool 5304-S is a 3/16" diameter 3-flute solid carbide square end mill built specifically for aluminum and non-ferrous machining, where fast feeds and a clean finish both matter in the same pass. It belongs to the Ferocious 3x 5300 Series, CGS Tool's aluminum-focused line.
What sets this tool apart is the combination of a ZrN coating, matched to aluminum cutting, with a wiper end and variable helix/pitch geometry that fights chatter at speed. It's built to hold a clean finish under strong stock removal in aluminum, copper, brass, non-ferrous material, plastics, and composites.
Tool Specifications:
- Diameter: 3/16"
- Shank: 3/16"
- Length of Cut (LOC): 1"
- Overall Length (OAL): 3"
- Flutes: 3 - Square End
- Material: Solid Carbide
- Coating: ZrN
- Series: Ferocious 3x 5300 Series
- Part No: 5304-S
Key Performance Features:
- 3-flute square end design for aluminum and non-ferrous milling
- ZrN coating supports cleaner aluminum cutting
- Wiper end geometry helps improve surface finish
- Variable helix and variable pitch reduce chatter and harmonics
- 1" LOC gives useful cutting reach for smaller features
- Rated for aluminum, copper, brass, non-ferrous metals, plastics, and composites
