Product Overview
The CGS Tool 720-1875 is a 3/16" diameter 2-flute solid carbide square end mill built specifically for general-purpose milling with a bit of added cutting reach over a standard-length tool. It belongs to the 720 Series, CGS Tool's extended-reach general-purpose line.
What sets this tool apart is the 3/4" length of cut, giving smaller slots and profiles more depth than a shorter tool at this diameter could reach. Running a 30° helix, and left uncoated, it holds up through mild steel, stainless, cast iron, titanium, non-ferrous material, plastics, and composites.
Tool Specifications:
- Diameter: 3/16"
- Shank: 3/16"
- Length of Cut (LOC): 3/4"
- Overall Length (OAL): 2-1/2"
- Flutes: 2 - Square End
- Material: Solid Carbide
- Coating: Uncoated
- Series: CGS 720 Series
- Part No: 720-1875
Key Performance Features:
- 2-flute square end design for general-purpose milling
- 3/4" LOC gives useful cutting reach
- 30° helix supports smooth chip movement
- Handles slots, profiles, plunge cuts, and side wall work
- Single-end solid carbide build
- Rated for mild steel, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites
