Product Overview
The CGS Tool 720-1875-ALTiN is a 3/16" diameter 2-flute solid carbide square end mill built for general-purpose milling jobs that need a bit more reach than a standard-length tool provides. Slots, compact profiles, side wall work — this tool is set up to handle all of it with the extra length of cut giving access into deeper features.
The ALTiN coating helps the edge resist heat and wear during tougher cutting, and with a 3/4" length of cut, 2-1/2" overall length, and 30° helix, the 720 Series keeps square-end performance dependable in smaller CNC applications across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites.
Tool Specifications:
- Diameter: 3/16"
- Shank: 3/16"
- Length of Cut (LOC): 3/4"
- Overall Length (OAL): 2-1/2"
- Flutes: 2 - Square End
- Material: Solid Carbide
- Coating: ALTiN
- Radius: No
- Series: CGS 720 Series
- Part No: 720-1875-ALTiN
Key Performance Features:
- General-purpose milling covered by a 2-flute square end build
- Extra reach comes from the 3/4" length of cut
- ALTiN coating adds heat and wear resistance
- 30° helix supports smooth, consistent chip movement
- Handles slots, profiles, plunge cuts, and side wall work
- Suited to mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites
