Product Overview
Deeper pocket work needs a ball end tool with real reach, and the 822-4375 provides it at 7/16" diameter. This 2-flute ball end mill carries a .2188" radius, giving the tool a smooth rounded cutting form for deeper pocket work, curved walls, and extended finishing passes.
With a 3" length of cut and 6" overall length, this cutter is useful when a shorter ball end mill can't reach the feature properly. The 30° helix and uncoated solid carbide body give steady general-purpose performance across mild steel, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites.
Tool Specifications:
- Diameter: 7/16"
- Shank: 7/16"
- Length of Cut (LOC): 3"
- Overall Length (OAL): 6"
- Flutes: 2 Flute
- End Style: Ball End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: .2188"
- Series: 822 Series
- Part No: 822-4375
Key Performance Features:
- 2-flute ball end built for long-reach contour milling
- .2188" radius supports smooth, rounded surfaces
- 3" length of cut gives extended cutting depth
- 6" overall length helps reach deeper features
- Handles profile, plunge, side wall, and finishing work
- Cuts mild steel, stainless, cast iron, titanium, non-ferrous, plastics, and composites
