Product Overview
Deep general-purpose work needs a tool that reaches without flexing, and the 840-7501 delivers that at 3/4" diameter with a full 4" length of cut. This 4-flute square end mill is built for tall side walls, deep profiles, and applications where standard-length cutters simply can't access the feature.
Precision CNC-ground cutting edges and a 30° helix keep this tool steady for stock removal across a broad range of shop materials. The uncoated carbide body makes it practical for mild steel, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites at depths a shorter tool won't reach.
Tool Specifications:
- Diameter: 3/4"
- Shank: 3/4"
- Length of Cut (LOC): 4"
- Overall Length (OAL): 7"
- Flutes: 4 Flute
- End Style: Square End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: No
- Series: 840 Series
- Part No: 840-7501
Key Performance Features:
- 4-flute square end built for deep-reach milling
- 4" length of cut gives extended cutting capability
- 7" overall length supports access into deeper features
- 30° helix helps maintain smooth chip control
- Handles slotting, profiling, plunging, and side wall milling
- Cuts mild steel, stainless, cast iron, titanium, non-ferrous, plastics, and composites
