842-7500-ALTiN

General Purpose

Write a Review
$667.66
4 flute solid carbide ball end mills are ideal for rough and finish milling in a large range of materials. These end mills can be used in slotting, profile, plunge and side wall milling. Designed with an industry standard 30° degree helix and precision cutting edges these end mills will perform above the competition.
SKU:
104197
Condition:
New
Shipping:
Calculated at Checkout
DIA:
3/4
SHANK:
3/4
LOC:
3
OAL:
6
FLUTES:
4 Flute
END STYLE:
Ball End
COATING:
ALTiN
Radius:
.375"
Adding to cart… The item has been added

Product Overview

The CGS Tool 842-7500-ALTiN is a 3/4" diameter 4-flute solid carbide ball end mill from the 842 Series, sized for long-reach profile and contour milling with a 3" length of cut and 6" overall length. It's built for deeper pockets and taller profile work.
Built on the same precision CNC equipment as CGS Tool's other general-purpose lines, it holds a 30° helix and a .375" radius matched to its diameter, with an ALTiN coating that protects the edge as heat builds during tougher milling. Rated across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites, it delivers smooth rounded surfaces at real depth.

Tool Specifications:

  • Diameter: 3/4"
  • Shank: 3/4"
  • Length of Cut (LOC): 3"
  • Overall Length (OAL): 6"
  • Flutes: 4 - Ball End
  • Material: Solid Carbide
  • Coating: ALTiN
  • Radius: .375"
  • Series: CGS General Purpose (842 Series)
  • Part No: 842-7500-ALTiN

Key Performance Features:

  • 4-Flute ball end design for long-reach contour milling
  • Extended LOC matched to diameter for cutting depth
  • ALTiN coating improves heat and wear resistance
  • .375" radius supports larger rounded surfaces
  • Effective across mild steels, stainless, cast iron, and titanium
  • Also suited to non-ferrous metals, plastics, and composites
