Product Overview
The CGS Tool CR123-5000.030 is a 1/2" diameter 2-flute solid carbide corner radius end mill from the CR123 Series, built for general-purpose milling where chip space and edge strength both matter. Its .030" radius supports the cutting corner while keeping part detail clean.
Built on the same precision CNC equipment as CGS Tool's other general-purpose lines, it holds a 30° helix matched to a practical, controlled cutting feel. Uncoated and rated across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites, it's suited to profiling, slotting, and side wall milling.
Tool Specifications:
- Diameter: 1/2"
- Shank: 1/2"
- Length of Cut (LOC): 1"
- Overall Length (OAL): 3"
- Flutes: 2 - Corner Radius
- Material: Solid Carbide
- Coating: Uncoated
- Radius: .030"
- Series: CGS CR123 Series
- Part No: CR123-5000.030
Key Performance Features:
- 2-Flute corner radius design for added edge strength
- .030" radius matched to diameter reduces sharp-corner wear
- 30° helix with precision-ground cutting edges
- Single-end solid carbide construction
- Effective across mild steels, stainless, cast iron, and titanium
- Also suited to non-ferrous metals, plastics, and composites
