Product Overview
Edge protection at 7/32" diameter — the CGS Tool 120-2188-ALTiN is a 2-flute square end mill from the 120 Series built for slotting, profiling, pocketing, and light stock removal.
The 2-flute design gives useful chip space, and ALTiN coating protects the cutting edge through heat and wear. Solid carbide construction handles mild steels, stainless, cast iron, titanium, non-ferrous materials, plastics, and composites.
Tool Specifications:
- Diameter: 7/32"
- Shank: 1/4"
- Length of Cut (LOC): 5/8"
- Overall Length (OAL): 2-1/2"
- Flutes: 2 - Square End
- Material: Solid Carbide
- Coating: ALTiN
- Helix: 30°
- Design: Single End
- Series: CGS 120 Series
- Part No: 120-2188-ALTiN
Key Performance Features:
- 2-flute square end design provides strong chip clearance
- ALTiN coating helps improve heat resistance and cutting edge life
- 30° helix supports smooth cutting and controlled chip movement
- Solid carbide construction provides rigidity and wear resistance
- Suitable for mild steels, stainless, cast iron, titanium, non-ferrous materials, plastics, and composites
- Built for slotting, profiling, pocketing, plunge milling, and side-wall milling
- Reliable 7/32" option for everyday general-purpose machining
