Product Overview
The uncoated version of the shop's go-to square end mill, the CGS Tool 120-7500 covers the same 3/4" diameter, 2-flute ground in the 120 Series — built for slots, profiles, plunge cuts, and side wall work without needing a coated edge to get through the job.
A 1-1/2" length of cut and 4" overall length give it dependable reach, and a 30° helix keeps chip movement smooth throughout. This single-end cutter runs across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites.
Tool Specifications:
- Diameter: 3/4"
- Shank: 3/4"
- Length of Cut (LOC): 1-1/2"
- Overall Length (OAL): 4"
- Flutes: 2 - Square End
- Material: Solid Carbide
- Coating: Uncoated
- Series: CGS 120 Series
- Part No: 120-7500
Key Performance Features:
- 2-flute square end built for general-purpose milling
- 3/4" diameter supports stronger stock removal
- 30° helix keeps chip flow smooth
- Good for slotting, profiling, plunge, and side wall milling
- Single-end solid carbide construction
- Works in mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites
