Product Overview
The CGS Tool 122-2188 is a 7/32" diameter 2-flute solid carbide ball end mill from the 122 Series, sized for profile milling and rounded pocket work that still needs enough reach for smaller part features. Its .1094" radius is built for a clean contour finish.
Built on the same precision CNC equipment as CGS Tool's other general-purpose lines, it holds a 30° helix matched to a 5/8" length of cut for practical reach. Uncoated and rated across mild steels, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites, it's a reliable general-purpose ball end mill.
Tool Specifications:
- Diameter: 7/32"
- Shank: 1/4"
- Length of Cut (LOC): 5/8"
- Overall Length (OAL): 2-1/2"
- Flutes: 2 - Ball End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: .1094"
- Series: CGS General Purpose (122 Series)
- Part No: 122-2188
Key Performance Features:
- 2-Flute ball end design for contour and profile milling
- .1094" radius matched to diameter for smooth toolpaths
- Useful LOC for reach in smaller applications
- 30° helix with precision-ground cutting edges
- Effective across mild steels, stainless, cast iron, and titanium
- Also suited to non-ferrous metals, plastics, and composites
