Product Overview
Radius control at 15/64" diameter. the CGS Tool 122-2344, is basically a 2-flute ball end mill , made under the single-end 122 Series, aimed at 3D milling , mold detailing, and blended surface work, The ball nose manages those rounded surface cuts fairly cleanly, and the 2-flute setup gives you better chip clearance while cutting , which helps in real life. It’s an uncoated carbide style, good for mild steels, stainless, cast iron, titanium, non ferrous materials, plastics, and composites too.
Tool Specifications:
- Diameter: 15/64"
- Shank: 1/4"
- Length of Cut (LOC): 3/4"
- Overall Length (OAL): 2-1/2"
- Flutes: 2 - Ball End
- Material: Solid Carbide
- Coating: Uncoated
- Helix: 30°
- Design: Single End
- Series: CGS 122 Series
- Part No: 122-2344
Key Performance Features:
- 2-flute ball end design for contouring and radius milling
- Ball nose profile supports smooth 3D surfaces and blended details
- 30° helix helps maintain controlled cutting and chip evacuation
- Solid carbide construction provides rigidity and repeatable accuracy
- Uncoated finish suited for general-purpose machining flexibility
- Suitable for mild steels, stainless, cast iron, titanium, non-ferrous materials, plastics, and composites
- Built for profiling, finishing passes, mold work, and surface blending
