Product Overview
The CGS Tool 142-0625 is a 1/16" diameter 4-flute solid carbide ball end mill built specifically for fine profile and contour milling, made for pockets small enough that only a miniature tool will do. It belongs to the 142 Series, CGS Tool's general-purpose ball nose line.
What sets this tool apart is the .0312" radius, sized for miniature pockets, surface blending, and light finishing, running on a 30° helix that keeps control tight in compact features. Left uncoated, it holds up through mild steel, stainless, cast iron, titanium, non-ferrous material, plastics, and composites.
Tool Specifications:
- Diameter: 1/16"
- Shank: 1/8"
- Length of Cut (LOC): 3/16"
- Overall Length (OAL): 1-1/2"
- Flutes: 4 - Ball End
- Material: Solid Carbide
- Coating: Uncoated
- Radius: .0312"
- Series: CGS 142 Series
- Part No: 142-0625
Key Performance Features:
- 4-flute ball end design for fine contour milling
- .0312" radius supports small rounded features
- 30° helix helps maintain smooth cutting control
- Compact size works well in tight details
- Handles finishing, blending, and small pocket machining
- Rated for mild steel, stainless, cast iron, titanium, non-ferrous metals, plastics, and composites
